JF Bimetal Bearings

Introduction Applications

JF Bimetallic bearings to high-quality low-carbon steel substrate, the surface of the sintered copper alloy having a low friction characteristics (CuPb10Sn10, CuPb6Sn6Zn3, CuPb24Sn4, CuPb30, AlSn20Cu, CuSn8Ni) as a wear layer bearing copper alloy surfaces can be processed in accordance with the use of a variety of conditions need type tank, oil hole, oil hole, so as to fit in unsustainable fuel refueling or difficult situations. Secondary extrusion material through the secondary sintering can be a good bonding strength and optimum carrying capacity.

Nominal Thickness	Tolerances+ of Series B (non-machinable)	Tolerances of Series C (non-machinable)
1.0	-0.025	+0.25 +0.15
1.5	-0.030	+0.25 +0.15
2.0	-0.035	+0.25 +0.15
2.5	-0.040	+0.30 +0.15
3.0	-0.045	+0.30 +0.15
3.5	-0.050	+0.30 +0.15

JF-800 Bimetal Bearings
The product is the double-bearing bearing capacity in the strongest one...
READ MORE >

JF-720 Bimetal Bearings
Better fatigue strength and load carrying capacity. Suitable for medium-speed medium load...
READ MORE >

JF-700 Bimetal Bearings
The product because of high lead content, so both good anti-bite axis and foreign body buried nature.
READ MORE >

JF-20 High Tin Aluminum Bearing
The product has medium fatigue strength and load carrying capacity...
READ MORE >
FB08G Solid Bearings
Lubrication area of more than 25%
Good lubricity and abrasion resistance
READ MORE >
